MODEL | HEIGHT | LENGTH | DEPTH | No. of Wells | Electical Lighting | Electrical volts & amps single phase | Electrical volts & amps three phase | Approx. Shipping Weight |
---|---|---|---|---|---|---|---|---|
MCH - 4 | 55" | 48" | 35" | 3 | 115V - 1.7 a | 208-240/1/60 - 13.5-15 a | 208-240/3/60 - 7.7-8.6 a | 550 lbs. |
MDL - 6 | 55" | 70" | 35" | 4 | 115V - 1.4 a | 208-240/1/60 - 18.3-20 a | 208-240/3/60 - 11.2-13 a | 650 lbs. |
MDL - 8 | 55" | 94" | 35" | 6 | 115V - 3.0 a | 208-240/1/60 - 27-30 a | 208-240/3/60 - 15.4-17.2 a | 800 lbs. |
NOTE: Designed for use in locations with air conditioning where temperature and relative humidity do not exceed 75% F and 55% RH.
(*) This size condenser unit is installed on this model.
(**) This size condenser unit is RECOMMENDED for this model. Consult a competent refrigeration mechanic to determine the appropriate size for your specific application. The appropriate condenser size will vary depending on length of run, indoor/outdoor use, etc.
We reserve the right to change the specifications without notice.
(+) Extreme high humidity conditions may require direct drains on S/C models.
