| MODEL | LENGTH | HEIGHT | DEPTH | No. of Wells | Electrical Lighting | Electrical Volts & amps Single Phase | Electrical Volts & amps Three Phase | Approx. Weight |
|---|---|---|---|---|---|---|---|---|
| WBCH-48 | 49 1/4" | 48 3/4" | 35" | 3 | 115V - 1.4a | 208-240/1/60 - 13.5-15a | 208-240/3/60 - 7.7-8.6a | 665 lbs. |
| WBCH-59 | 49 1/4" | 59 3/4" | 35" | 3* | 115V - 1.4a | 208-240/1/60 - 13.5-15a | 208-240/3/60 - 7.7-8.6a | 780 lbs. |
| WBCH-77 | 49 1/4" | 77 3/4" | 35" | 5 | 115V - 1.4a | 208-240/1/60 - 20.3-25.0a | 208-240/3/60 - 15.4-17.2a | 970 lbs. |
NOTE: The WBCH-59 will accommodate only 3 well openings, not 4.
We reserve the right to change specifications and/or colors of interior and/or exterior parts at our own discretion without notice.
(+) Extreme high humidity conditions may require direct drains on S/C models.
